Custom ECU tuning for Chevrolet Express and GMC Savana full-size vans across all engine options from 1998–2023. Performance, drivability, fuel economy, and transmission calibration tailored to your van's setup and use case — daily driver, conversion van, work van, or tow rig.
Detailed Engine, Transmission & Chassis Coverage
Engines:
4.3L L35 V6 (1996–2002)
5.0L L30 V8 (1996–2002)
5.7L L31 V8 (1996–2002)
7.4L L29 V8 (1996–2000)
8.1L L18 V8 (2001–2002)
4.3L Vortec 4300 / LU3 V6 (2003–2014)
4.3L EcoTec3 4300 / LV1 V6 (2018–present) [requires PCM unlocking]
4.8L Vortec 4800 / LR4 V8 (2003–2007)
4.8L Vortec 4800 / LY2 V8 (2008–2009)
4.8L Vortec 4800 / L20 Flex Fuel V8 (2010–2017)
5.3L Vortec 5300 / LM7 V8 (2003–2007)
5.3L Vortec 5300 / LMF Flex Fuel V8 (2008–2014)
6.0L Vortec 6000 / LQ4 V8 (2003–2007)
6.0L Vortec 6000 / LY6 V8 (2008–2009)
6.0L Vortec 6000 / L96 Flex Fuel V8 (2010–2020)
Transmissions:
4L60E — 1500 series and light-duty 2500 (1996–2014)
4L80E — Heavy-duty 2500 and 3500 (1996–2009)
6L90E — Heavy-duty 2500 and 3500 (2010–2023)
8L90E — 4.3L EcoTec3 V6 (2017–present)
Chassis Configurations:
Standard cargo van and passenger van
Cutaway chassis (1997–present) — includes box trucks, RV chassis, shuttle bus, and commercial upfit applications
What's Included:
Full engine calibration — fuel tables, spark timing, torque management, idle quality, fan control, speed limiter removal, and rev limiter adjustment. Transmission tuning available for 4L60E, 4L80E, 6L80E, 6L90E and 8L90E. Tire size and gear ratio correction included for re-geared or oversized tire setups.
Common requests for vans include towing-specific calibrations (firmer shifts, raised line pressure, locked TCC strategy), fuel economy tuning for unloaded driving, and drivability fixes for high-mileage vans with worn sensors.
We can make adjustments for various engine modifications as well as engine swaps.
HP and Torque increase for a stock/bolt on engine will be similar to the following.
HP and Torque increase for a stock/bolt-on engine will be similar to the following:
4.3L V6: 10-20 HP / 20-25 TQ
4.8L / 5.3L V8: 15-25 HP / 25-35 TQ
6.0L V8: 20-30 HP / 30-40 TQ
8.1L V8: 25-35 HP / 35-45 TQ
Your computer will be adjusted per your vehicle specifications to get the most out of your vehicle. Fuel and spark tables will be modified accordingly. We can modify almost anything in the computer programming, just some of the things you might want to think about are:
What We Can Adjust:
Fan 1 and 2 Temperature On and Off Change
90 second fan on at key-off (this feature activates when engine coolant is (Your Thermostat Temp) degrees or greater)
Delete VATS (E69 PCM Does Not Have VATS)
Change Axle Ratio
Change Tire Size
Remove speed limiter
Remove torque management - Torque abuse modes are modified to eliminate bog at launch
Remove unused engine codes (Leave in notes what you need turned off)
Emissions equipment deletes are intended for off-road, race, or competition use only and are not legal for street-driven vehicles. Customer is responsible for compliance with local laws.
Remove throttle lag
Fueling modified for WOT (Wide Open Throttle) performance
Timing modified for WOT performance
Raised rev limiter
Raised shift points
Removes lag by changing downshift tables
Transmission line pressure increased
MAF calibration is year specific
PE engagement adjusted to reduce KR
Torque converter lockup tables modified to improve transmission life and eliminate converter lockup hunting
Correct VIN number
Enable E85 Flex Fuel
Note on 2018+ 4.3L V6 Models: Late-model 4.3L Express vans use a locked PCM (T87A platform) that requires unlocking before any tuning can be done. The unlocking service is $299.99 in addition to the tune. This is a one-time cost — once unlocked, future revisions don't require it again.
